Non Rotating Wire Ropes own a particular structure, which make them quite special. Such wire ropes contain more strands than the inter strands’ wires. Various structures are available: 7 * 19, 7 * 37, 7 * 40 and etc.

Layer Turnings’ type are different. Not only does it increase the torsional resistance but also rise the abrasion resistance.

Construction: 7 × 19 (18 * 7  + IWRC) (12/6/1)

Type of Band: Normal Right or Left hand Turn (RHOL or LHOL, RHLL or LHLL)

Tensile: 1770 N/mm² , 1960 N/mm²

Standard: BS302, EN 12385 -4, DIN 3069

Type of Lubricant: Cardium Compound Fluid
